| Mould on Straight Arm | 2000 X 2, 1500 X 2, 1000 X 6, 500 X8 |
|---|---|
|
Mould on Offset Arm |
3000 X 1, 5000 X 1 |
|
Total Cycle Time |
35 min (For Double Layer) for St. Arm and 45 Min For offset Arm* |
|
Production Per day |
2,16,000 liter Max (24 hrs) |
|
Production Capacity |
160 Tanks/Day ofall size |
|
Electrical Load |
40 kW (53 Hp) (415 Volt 3 Phase) |
|
Process Temperature |
180 °C-220 °C |
|
Machine suitable for |
Double Layer, Triple Layer, Four Layer or Foam layer |
|
Manpower |
4 Semi Skilled Persons Per Shift |
|
Machine Dimension |
20 meter X 14 meter X 9 meter |
|
Power |
Connected /Running Load = 19 kw (26 HP) |
|
LPG Consumption |
18 kg/h or 10 kg/Cycle |
Note: Technical specifications are subject to modification without prior notice.
